ADP163AUJZ-R7 Positive Linear Regulators (LDO) by Analog Devices
| Status: | Production |
|---|---|
| Series: | ADP163 |
| RoHS: | Compliant |
Features
| Ultralow quiescent current IQ = 560 nA with 0 μA load, IQ = 860 nA with 1 μA load |
| Stable with 1 μF ceramic input and output capacitors |
| Input voltage range: 2.2 V to 5.5 V |
| Low shutdown current: <50 nA typical |
| Low dropout voltage: 195 mV @ 150 mA load |
| Maximum output current: 150 mA |
| Initial accuracy: ±1% |
| Accuracy over line, load, and temperature: ±3.5% |
| 15 fixed output voltage options: 1.2 V to 4.2 V |
| Adjustable output available |
| PSRR performance of 72 dB @ 100 Hz |
| See data sheet for additional features |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| 150mA LDO Adj Vout | Analog Devices |
