5025840360 CLIK-Mate by Molex
1.50mm Pitch, CLIK-Mate PCB Receptacle, Single Row, Surface Mount, Vertical, Tin Plating, Positive Lock, with Pick-and-Place Polyimide Tape, 3 Circuits, Beige
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: | 502584-0360 |
Where to Buy
Prices starting from US$0.33
| Distributor | Stock | ||
|---|---|---|---|
|
TTI Europe
from US$0.40
|
8,100
in stock
|
Buy Now |
|
Conrad
from US$0.93
|
4,500
in stock
|
Buy Now |
|
Farnell
from US$0.50
|
4,050
in stock
|
Buy Now |
|
TME
from US$0.55
|
914
in stock
|
Buy Now |
|
Avnet America
from US$0.33
|
900
in stock
|
Buy Now |
|
Newark Electronics
from US$0.56
|
528
in stock
|
Buy Now |
|
element14
from US$0.73
|
528
in stock
|
Buy Now |
|
RS
from US$0.67
|
10
in stock
|
Buy Now |
|
Avnet Abacus
-
|
4,500
in stock
|
Buy Now |
|
|
RS Americas
from US$0.74
|
0
in stock
|
Buy Now |
|
|
TTI Americas
from US$0.37
|
0
in stock
|
Buy Now |
|
Sager
from US$0.41
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.42
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.40
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.37
|
0
in stock
|
Buy Now |
|
|
Avnet Asia
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | CLIK-Mate |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 2.0A |
| Voltage Maximum | 100V |
Physical |
|
|---|---|
| Circuits Loaded | 3 |
| Circuits Maximum | 3 |
| Color Resin | Beige |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Glow Wire Capable | No |
| Guide To Mating Part | No |
| Keying To Mating Part | No |
| Lock To Mating Part | Yes |
| Mated Height | 9.70mm |
| Material Metal | Copper Alloy |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Net Weight | 452.000/mg |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Pcb Locator | No |
| Pcb Retention | Yes |
| Pitch Mating Interface | 1.50mm |
| Pitch Termination Interface | 1.50mm |
| Plating Min Termination | 1.000µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | No |
| Robotic Placement | Vacuum Pick-Up Tape |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Surface Mount |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| 1.5MM CLIKMATE PCB RCPT 3P | TTI Europe |
| Molex Einbau-Stiftleiste (Standard) Polzahl Gesamt 3 Rastermaß: 1.5 mm 5025840360 1 St. Tape on Full reel | Conrad |
| CONN, RCPT, 3POS, 1.5MM, SMT | Farnell |
| Contact | TME |
| Conn Wire to Board Receptacle 3 POS 1.5mm Solder ST Surface Mount | Avnet America |
| Wtb Conn, Rcpt, 3Pos, 1Row, 1.5Mm | Newark Electronics |
| WTB CONN, RCPT, 3POS, 1ROW, 1.5MM | element14 |
| Molex 502584-0360 PCB Socket | RS |
| 1.5 W/BSGLSTASSY3CKTBEIGEEMBSTPPKG | RS Americas |
| 1.50MM CLIK-MATE REC 03P VT | TTI Americas |
| Headers & Wire Housings 1.5 W/BSglSTAssy3CktBeigeEmbsTpPkg | Sager |
| 1.5 W/BSGLSTASSY3CKTBEIGEEMBS PPKG | Heilind Americas |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 5025840360?
Additional datasheets, footprints and schematics for 5025840360 are listed on our Part Details page. You can also find images and similar parts to 5025840360 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 5025840360 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 5025840360 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 5025840360 fall under?
The 5025840360 is listed under PCB Headers and Receptacles.
Can I view similar or alternative parts?
You can view similar parts to 5025840360 when available in the PCB Headers and Receptacles range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 5025840360 you can contact the distributor directly for product support, shipping queries etc.
Is the 5025840360 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 5025840360 have stock available?
Authorised distributors including TTI Europe, Conrad, Farnell, TME and Avnet America have stock available or on a lead time for 5025840360.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 5025840360 often in real-time on the comparison pages.
What if I can't find stock of 5025840360?
You can fill out our help required form which you can use to request a quote for 5025840360 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
