5023861070 CLIK-Mate by Molex
1.25mm Pitch CLIK-Mate Wire-to-Board PCB Receptacle, Single Row, Right-Angle, Tin (Sn) Plating, 10 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: | 502386-1070 |
Where to Buy
Prices starting from US$0.28
| Distributor | Stock | ||
|---|---|---|---|
|
Farnell
from US$0.62
|
8,400
in stock
|
Buy Now |
|
Conrad
from US$0.59
|
8,009
in stock
|
Buy Now |
|
TTI Americas
from US$0.45
|
3,600
in stock
|
Buy Now |
|
Heilind Americas
from US$0.54
|
1,800
in stock
|
Buy Now |
|
Newark Electronics
from US$0.77
|
552
in stock
|
Buy Now |
|
element14
from US$0.72
|
552
in stock
|
Buy Now |
|
Rutronik
from US$0.32
|
0
in stock
|
Buy Now |
|
RS
from US$0.47
|
0
in stock
|
Buy Now |
|
Avnet America
from US$0.47
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$0.73
|
0
in stock
|
Buy Now |
|
|
TTI Europe
from US$0.47
|
0
in stock
|
Buy Now |
|
Sager
from US$0.45
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.28
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.48
|
0
in stock
|
Buy Now |
|
EME
from US$0.38
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | CLIK-Mate |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 1.0A |
| Voltage Maximum | 50V AC (RMS)/DC |
Physical |
|
|---|---|
| Circuits Loaded | 10 |
| Circuits Maximum | 10 |
| Color Resin | Natural |
| Durability Mating Cycles Max | 30 |
| First Mate Last Break | No |
| Gender | Female |
| Glow Wire Capable | No |
| Guide To Mating Part | Yes |
| Keying To Mating Part | Yes |
| Lock To Mating Part | Yes |
| Mated Height | 5.55mm |
| Material Metal | Copper Alloy |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | High Temperature Thermoplastic |
| Net Weight | 453.601/mg |
| Number Of Rows | 1 |
| Orientation | Right Angle |
| Pcb Locator | No |
| Pcb Retention | Yes |
| Pitch Mating Interface | 1.25mm |
| Pitch Termination Interface | 1.25mm |
| Plating Min Mating | 1.016µm |
| Plating Min Termination | 1.016µm |
| Polarized To Mating Part | Yes |
| Polarized To Pcb | No |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Surface Mount |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| CONN, R/A RCPT, 10POS, 1.25MM, SMT | Farnell |
| Molex Einbau-Stiftleiste (Standard) Polzahl Gesamt 10 Rastermaß: 1.25 mm 5023861070 1 St. Tape on Full reel | Conrad |
| 1.25MM CLIK-MATE REC 10P RA SN | TTI Americas |
| 1.25 W/B SGL R/A REC ASSY 10C TEMBSTPPKG | Heilind Americas |
| Connector, Rcpt, 10Pos, 1Row, 1.25Mm | Newark Electronics |
| CONNECTOR, RCPT, 10POS, 1ROW, 1.25MM | element14 |
| 10P CLICKMATE 1,25MM RIGHTANGLE | Rutronik |
| Molex 502386-1070 Base Strip | RS |
| Conn Wire to Board RCP 10 POS 1.25mm Solder RA SMD Embossed T/R | Avnet America |
| CLIK-MATE SERIES 1.25MM 10 WAY 1 ROW RIGHT ANGLE PCB SOCKET SMNT WIRE TO BOARD | RS Americas |
| 1.25MM PITCH CLIK-MATE | TTI Europe |
| Headers & Wire Housings 1.25MM CLIK-MATE REC 10P RA SN | Sager |
