393900103 Eurostyle Fixed Mount by Molex
9.52mm Pitch Beau Eurostyle Fixed Mount PCB Terminal Block, Modular, 3 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
39390-0103,
0393900103, MX-MSP0300N-0N |
Specifications
| Product Name | Eurostyle Fixed Mount |
|---|---|
| Application | Wire-to-Board |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 30.0A |
| Voltage Maximum | 600V |
Physical |
|
|---|---|
| Circuits Loaded | 3 |
| Circuits Maximum | 3 |
| Color Resin | Black |
| Entry Angle | Horizontal |
| Lock To Mating Part | No |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Panel Mount | No |
| Pcb Retention | No |
| Pcb Thickness Recommended | 4.00mm |
| Pc Tail Length | 5.20mm |
| Pitch Mating Interface | 9.53mm |
| Pitch Termination Interface | 9.53mm |
| Polarized To Mating Part | N/A |
| Stackable | Yes |
| Temperature Range Operating | 110°C |
| Wire Size Awg | 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30 |
| Wire Size Mm | 0.05-2.50 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| TERMINAL BLOCK,3 CONTACTS,0.375 PITCH,PC TAIL TERMINAL | element14 |
| EUROSTYLE 9 53 FIXED PIN 3 CIR | Heilind Europe |
| TERMINAL BLOCK,3 CONTACTS,0.375 PITCH,PC TAIL TERMINAL 01J7823 | Farnell |
| Conn Eurostyle Block 3 POS 9.53mm Solder ST Thru-Hole 30A/Contact | Avnet Abacus |
