391002210 Eurostyle Two Screw by Molex
12.00mm Pitch, Beau Eurostyle Two-Screw Terminal Strips, 10 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
39100-2210,
0391002210, M800-03-10-5-M1 |
Specifications
| Product Name | Eurostyle Two Screw |
|---|---|
| Application | Wire-to-Wire |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 40.0A |
| Voltage Maximum | 600V |
Physical |
|
|---|---|
| Circuits Loaded | 10 |
| Circuits Maximum | 10 |
| Color Resin | White |
| Entry Angle | Horizontal |
| Lock To Mating Part | No |
| Material Metal | Stainless Steel, Steel |
| Material Resin | Nylon |
| Net Weight | 40.830/g |
| Number Of Rows | 2 |
| Orientation | Vertical |
| Panel Mount | Mounting Holes Between Circuit |
| Pitch Mating Interface | 12.00mm |
| Pitch Termination Interface | 12.00mm |
| Polarized To Mating Part | N/A |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Screw |
| Wire Size Awg | 8, 10, 12, 14, 16, 18, 20 |
| Wire Size Mm | 0.52-8.37 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Term Strip 12Mm High Prof 10 Cir Wht |Molex 39100-2210 | Newark Electronics |
| TERMINAL BLOCK, BARRIER, 10POS, 8AWG | element14 |
| TERM STRIP 12MM HIGH PROF IR WHT | Heilind Americas |
