2016060620 Universal Clamp by Molex
High Current Universal Clamp Terminal Block, 35.00mm DIN-rail or Screw Mount, 230.0A / 600V, Grey Housing and Cover, 1 Circuit
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
201606-0620,
MX-KE62 |
Where to Buy
Prices starting from US$7.81
| Distributor | Stock | ||
|---|---|---|---|
|
Waytek
from US$8.43
|
118
in stock
|
Buy Now |
|
Heilind Americas
from US$8.33
|
70
in stock
|
Buy Now |
|
Newark Electronics
from US$11.23
|
0
in stock
|
Buy Now |
|
Avnet America
from US$7.81
|
0
in stock
|
Buy Now |
|
RS Americas
from US$11.73
|
0
in stock
|
Buy Now |
|
element14
from US$14.31
|
0
in stock
|
Buy Now |
|
TTI Americas
from US$8.18
|
0
in stock
|
Buy Now |
|
Sager
from US$9.30
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$11.98
|
0
in stock
|
Buy Now |
|
Farnell
from US$14.20
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Universal Clamp |
|---|---|
| Application | Wire-to-Wire |
Electrical |
|
|---|---|
| Current Maximum Per Contact | 230.0A |
| Voltage Maximum | 600V |
Physical |
|
|---|---|
| Circuits Loaded | 1 |
| Circuits Maximum | 1 |
| Color Resin | Gray |
| Entry Angle | Horizontal |
| Lock To Mating Part | No |
| Material Metal | Aluminum |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | Polyamide (PA) |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Panel Mount | Screws |
| Pitch Mating Interface | N/A |
| Polarized To Mating Part | N/A |
| Stackable | No |
| Temperature Range Operating | -40° to +105°C |
| Termination Interface Style | Screw |
| Wire Size Awg | 2(2-6), 4/0-4, 6+6+6 |
| Wire Size Mm | 13.30+13.30+13.30, 2(13.30-33.60), 21.00-107.00 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| HI CURR UNV CLMP TRM BLK,1P DIN-RL/SCR MT,230A/600V | Heilind Americas |
| Terminal Block, Dinrail, 1Pos, 0Awg | Newark Electronics |
| Universal Clamp Terminal Block High Current 1 Circuit 35mm DIN-rail/Screw Mount 230A/600V Gray Housing Gray Cover Polyamide | Avnet America |
| TERMINAL BLOCK, DINRAIL, 1POS, 0AWG | element14 |
| HIGH CURRENT TERMINAL BLOCK | TTI Americas |
| Fixed Terminal Blocks HIGH CURRENT TERMINAL BLOCK | Sager |
