191640015 Perma-Seal by Molex
Perma-Seal Male Quick Disconnect Tab for 22-18 AWG Wire, Tab Size 6.35 x 0.81mm, Carton
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
19164-0015,
0191640015, SAA-9260 |
Where to Buy
Prices starting from US$0.38
| Distributor | Stock | ||
|---|---|---|---|
|
Waytek
from US$0.40
|
40,705
in stock
|
Buy Now |
|
Heilind Americas
from US$0.38
|
21,482
in stock
|
Buy Now |
|
Newark Electronics
from US$0.55
|
9,150
in stock
|
Buy Now |
|
Conrad
from US$0.88
|
8,150
in stock
|
Buy Now |
|
Farnell
from US$0.69
|
7,785
in stock
|
Buy Now |
|
TTI Americas
from US$0.39
|
4,554
in stock
|
Buy Now |
|
RS Americas
from US$0.82
|
482
in stock
|
Buy Now |
|
|
RS
from US$0.67
|
150
in stock
|
Buy Now |
|
Lake-View Electronics
-
|
5,251
in stock
|
Buy Now |
|
Avnet Abacus
-
|
2,000
in stock
|
Buy Now |
|
Avnet America
from US$0.43
|
0
in stock
|
Buy Now |
|
TME
from US$0.66
|
0
in stock
|
Buy Now |
|
element14
from US$0.61
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.49
|
0
in stock
|
Buy Now |
|
|
TTI Asia
from US$0.49
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | Perma-Seal |
|---|
Electrical |
|
|---|---|
| Voltage Maximum | 600V |
Physical |
|
|---|---|
| Barrel Type | Closed |
| Color Resin | Red |
| Gender | Male |
| Glow Wire Capable | No |
| Insulated | Partial |
| Insulation | NiAc |
| Lock To Mating Part | No |
| Material Metal | Brass |
| Material Plating Mating | Zinc Chromate |
| Material Plating Termination | Zinc Chromate |
| Material Resin | Nylon |
| Net Weight | 1.633/g |
| Orientation | Straight |
| Plating Min Mating | 5.080µm |
| Plating Min Termination | 5.080µm |
| Tab Thickness | 0.81mm |
| Tab Width | 6.35mm |
| Temperature Range Operating | -55° to +125°C |
| Wire Insulation Diameter | 3.81mm max. |
| Wire Size Awg | 18, 20, 22 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| 22-18 MALE COUPLER PERMA-SEAL (SAA-9260) | Heilind Americas |
| 22-18 Male Coupler Perma-Seal (Saa-9260) |Molex 19164-0015 | Newark Electronics |
| Molex 191640015 Flachstecker 1 St. Bulk | Conrad |
| CRIMP TERMINALS - CONNECT AND DISCONNECT | Farnell |
| FTAB-DSC|22-18|250X032|H/S|RED | TTI Americas |
| Molex 19164-0015 Spade Connector | RS |
| Quick Disconnect Terminal, Perma-Seal 19164, Male Quick Disconnect, 6.35mm x 0.81mm, 0.25" x 0.032""" | Avnet Abacus |
| Terminal: flat | TME |
| MALE DISCONNECT, 6.35MM, 22-18AWG, RED | element14 |
