190380007 InsulKrimp by Molex
InsulKrimp Snap Receptacle, for 16-14 AWG Wire, PVC, Fits Male Plug Diameter 3.96mm, Carton
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
19038-0007,
0190380007, BRB-2156 |
Where to Buy
Prices starting from US$0.10
| Distributor | Stock | ||
|---|---|---|---|
|
TTI Americas
from US$0.15
|
14,350
in stock
|
Buy Now |
|
Heilind Americas
from US$0.13
|
8,985
in stock
|
Buy Now |
|
RS Americas
from US$0.10
|
3,675
in stock
|
Buy Now |
|
|
RS
from US$0.27
|
1,950
in stock
|
Buy Now |
|
Newark Electronics
from US$0.14
|
1,202
in stock
|
Buy Now |
|
element14
from US$0.15
|
1,202
in stock
|
Buy Now |
|
Farnell
from US$0.15
|
1,202
in stock
|
Buy Now |
|
Lake-View Electronics
-
|
50,298
in stock
|
Buy Now |
|
Avnet Abacus
-
|
4,000
in stock
|
Buy Now |
|
Avnet America
from US$0.17
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.10
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | InsulKrimp |
|---|
Electrical |
|
|---|---|
| Voltage Maximum | 600V |
Physical |
|
|---|---|
| Barrel Type | Closed |
| Color Resin | Blue |
| Flammability | 94V-0 |
| Gender | Female |
| Glow Wire Capable | No |
| Insulated | Fully |
| Insulation | PVC |
| Lock To Mating Part | No |
| Material Metal | Brass |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | PVC |
| Net Weight | 1.123/g |
| Orientation | Straight |
| Plating Min Mating | 2.540µm |
| Plating Min Termination | 2.540µm |
| Tab Thickness | N/A |
| Tab Width | N/A |
| Termination Interface Style | Crimp or Compression |
| Wire Insulation Diameter | 3.81mm max. |
| Wire Size Awg | 14, 16 |
| Wire Size Mm | 1.00-2.50 |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| SSKT-DSC|16-14|.156 |VYL|BLU | TTI Americas |
| SNAP PLUG RECEPT. INSULKRIMP BRB-2156) | Heilind Americas |
| Molex 190380007 Ring Terminal | RS |
| Terminal, Female Bullet, Crimp, Blue | Newark Electronics |
| TERMINAL, FEMALE BULLET, CRIMP, BLUE | element14 |
| Snap Plug Terminal 14-16AWG F 25.4mm 7.6mm Tin Box | Avnet Abacus |
