15388040 SL by Molex
SL Single Row, Female, Version G Receptacle, Tin (Sn) Plating, 4 Circuits
| Status: | Active |
|---|---|
| Series: | - |
| RoHS: | Compliant |
| Aliases: |
15-38-8040,
0015388040, 70430-0143 |
Where to Buy
Prices starting from US$0.42
| Distributor | Stock | ||
|---|---|---|---|
|
RS
from US$0.88
|
3,702
in stock
|
Buy Now |
|
Newark Electronics
from US$0.87
|
1,787
in stock
|
Buy Now |
|
element14
from US$0.64
|
1,787
in stock
|
Buy Now |
|
Farnell
from US$1.12
|
1,787
in stock
|
Buy Now |
|
Avnet America
from US$0.80
|
0
in stock
|
Buy Now |
|
|
RS Americas
from US$1.22
|
0
in stock
|
Buy Now |
|
Conrad
from US$0.90
|
0
in stock
|
Buy Now |
|
TTI Americas
from US$0.61
|
0
in stock
|
Buy Now |
|
|
TTI Europe
from US$0.60
|
0
in stock
|
Buy Now |
|
Heilind Americas
from US$0.68
|
0
in stock
|
Buy Now |
|
|
Heilind Europe
from US$0.42
|
0
in stock
|
Buy Now |
|
Avnet Abacus
-
|
0
in stock
|
Buy Now |
| Buy Now |
Specifications
| Product Name | SL |
|---|
Electrical |
|
|---|---|
| Current Maximum Per Contact | 1.0A, 2.0A |
| Voltage Maximum | 250V |
Physical |
|
|---|---|
| Actuator Type | N/A |
| Circuits Loaded | 4 |
| Circuits Maximum | 4 |
| Color Resin | Black |
| Contact Position | N/A |
| Durability Mating Cycles Max | 25 |
| Material Metal | Phosphor Bronze |
| Material Plating Mating | Tin |
| Material Plating Termination | Tin |
| Material Resin | Polyester |
| Net Weight | 0.832/g |
| Number Of Rows | 1 |
| Orientation | Vertical |
| Pcb Mounting | N/A |
| Pcb Retention | N/A |
| Pitch Mating Interface | 2.54mm |
| Pitch Termination Interface | 2.54mm |
| Plating Min Mating | 3.810µm |
| Plating Min Termination | 1.905µm |
| Polarized To Pcb | N/A |
| Stackable | Yes |
| Temperature Range Operating | -40° to +105°C |
| Wire Cable Type | FFC/FPC |
Last 6 months Inventory & Pricing History
Alternative Descriptions
| Molex 15388040 FPC Connector | RS |
| Sl Ffc/Fpc Opt G Female Tin 4Ckt Rohs Compliant: Yes |Molex 15-38-8040 | Newark Electronics |
| CONNECTOR, FFC/FPC, 4POS, 1ROW, 2.54MM | element14 |
| Conn IDC Connector F 4 POS 2.54mm IDT ST Cable Mount Tube | Avnet America |
| SL FFC/FPC OPT G FEMALE TIN 4CKT | RS Americas |
| Molex Buchsengehäuse-Kabel Polzahl Gesamt 4 15388040 1 St. Tube | Conrad |
| SL 2.54MM REC 1X04 VERS G FEM | TTI Americas |
| SL SINGLE ROW, FEMALE, 4CKT | TTI Europe |
| SL FFC/FPC OPT G FEMALE TIN 4 KT | Heilind Americas |
Frequently Asked Questions
Where can I find additional details, specifications and documents for a 15388040?
Additional datasheets, footprints and schematics for 15388040 are listed on our Part Details page. You can also find images and similar parts to 15388040 on this page.
What pricing and inventory information can I view?
Distributor pricing and stock information is available for 15388040 on our Product Comparison page. Access via the 'View Pricing & Stock' button to view 15388040 price breaks, MOQs, lead times, inventory and SKUs from distributors.
What category does 15388040 fall under?
The 15388040 is listed under FFC / FPC Connectors.
Can I view similar or alternative parts?
You can view similar parts to 15388040 when available in the FFC / FPC Connectors range under the specifications section at the bottom of the details page.
Who can I contact for technical support of the product?
Submit any questions directly to the customer support team of the distributor listing the product. For the 15388040 you can contact the distributor directly for product support, shipping queries etc.
Is the 15388040 RoHS compliant?
Yes. This part has been flagged as RoHS Compliant by Molex.
Which authorised distributors for 15388040 have stock available?
Authorised distributors including RS, Newark Electronics, element14, Farnell and Avnet America have stock available or on a lead time for 15388040.
How do I check stock and lead times for all distributors?
Stock availability and lead times will be displayed for 15388040 often in real-time on the comparison pages.
What if I can't find stock of 15388040?
You can fill out our help required form which you can use to request a quote for 15388040 from some of our verified obsolescence suppliers. Alternatively, contact us via our web chat in the bottom left of your screen and one of our team will try to help.
